Measure your exceptional product with an exceptional price!
The SDS1000X HD series employs Siglent’s SPO technology with a maximum waveform capture rate of up to 120,000 wfm/ s (normal mode, up to 500,000 wfm/s in Sequence mode), 256-level intensity grading display function plus a color temperature display mode. It also employs an innovative digital trigger system with
high sensitivity and low jitter. The trigger system supports multiple powerful triggering modes including serial bus triggering. Tools such as History waveform recording, Search and Navigate functions, Mask Test, Bode Plot, Power Analysis and allow for extended waveform records to be captured, stored, and analyzed. An impressive array of measurement and math capabilities, options for a 25MHz arbitrary waveform generator, as well as serial decoding, are also features of the SDS1000X HD.
Main Features
-
100 MHz, 200 MHz bandwidth models
-
12-bit high resolution
-
Sampling rate up to 2 GSa/s
-
Memory depth up to 100 Mpts
-
Waveform capture rate up to 500,000 wfm/s (Sequence mode)
-
Noise floor as low as 70 μVrms at 200 MHz full bandwidth
Download here
Specifications
100 MHz, 200 MHz
Bandwidth
Trigger Type
Edge, Slope, Pulse width, Window, Runt, Interval, Dropout, Pattern, Video, Qualified, Nth edge, Delay, Setup/Hold time, Serial
One channel mode: 2 GSa/s,
Two channel mode: 1 GSa/s,
Four channel mode: 500 MSa/s
Sampling Rate (max.)
Serial Trigger and Decode
I2C, SPI, UART, CAN, LIN, CAN FD(Decode Only), FlexRay(Decode Only)
Waveform Capture Rate (max.)
Normal mode : 120,000 wfm/s;
Sequence mode : 500,000 wfm/s
Data Analysis
Search, Navigate, History, Mask Test, Counter, Bode plot, and Power Analysis
2/4 + EXT
Analog Channels
Digital Channel (optional)
16-channel; maximum sample rate up to 1 GSa/s; record length up to 10 Mpts
Display
10.1 TFT-LCD with capacitive touch screen (1024*600)
Memory Depth (max.)
One channel mode: 100 Mpts/ch,
Two channel mode: 50 Mpts/ch,
Four channel mode: 25 Mpts/ch
Math
4 traces4 traces
2 Mpts FFT, Filter, +, -, x, ÷, ∫dt, d/dt, √, Identity, Negation, Absolute, Sign, ex, 10x, ln, lg, Interpolation, MaxHold, MinHold, ERES, Average. Supports formula editor
I/O
USB 2.0 Host x3, USB 2.0 Device, 10 M / 100 M LAN, External trigger, Auxiliary output (TRIG OUT, PASS/FAIL), SBUS (Siglent MSO)
Model | Bandwidth | Channels | Resolution | Sampling Rate | Waveform Update Rate | Memory Depth |
|---|---|---|---|---|---|---|
SDS1204X HD | 200 MHz | 4 + EXT | 12-bit | 2 GSa/s | 500,000 wfm/s | 100 Mpts/ch |
SDS1202X HD | 200 MHz | 2 + EXT | 12-bit | 2 GSa/s | 500,000 wfm/s | 100 Mpts/ch |
SDS1104X HD | 100 MHz | 4 + EXT | 12-bit | 2 GSa/s | 500,000 wfm/s | 100 Mpts/ch |
SDS1102X HD | 100 MHz | 2 + EXT | 12-bit | 2 GSa/s | 500,000 wfm/s | 100 Mpts/ch |
