| Bandwidth |
350 MHz 、500 MHz 、1 GHz |
| Sample Rate(Max.) |
5 GSa/s |
| Waveform capture rate(Max.) |
500,000 wfm/s |
| Analog channels |
2 + EXT(Discontinued)/4 + EXT
|
| Trigger type |
Edge, Slope, Pulse width, Window, Runt, Interval, Dropout, Pattern, Video, Qualifed |
| Serial trigger and decode |
I2C, SPI, UART, CAN, LIN, CAN FD, FlexRay, I2S, MIL-STD-1553B |
| Digital channel |
16-channel; maximum waveform capture rate up to 1.25 GSa/s; record length up to 62.5 Mpts |
| Waveform generator (optional) |
Single channel, frequency up to 25 MHz, 125 MSa/s sample rate, 16 kpts waveform memory |
| I/O |
USB Host, USB Device, LAN, Pass/Fail, Trigger Out, 10 MHz In, 10 MHz Out, VGA Output |
| Probe (standard) |
1 probe supplied for each channel |
| Display |
10.1” TFT-LCD with capacitive touch screen (1024*600) |
|
|
